LA5c UHP

For agency quotes and individual officer discounts, please email us at sales@zbarsupply.com

Disclaimer for Full Power Laser Sales:

Please note that full-power (restricted) lasers are intended for military and law enforcement use only. Orders placed by individuals or organizations not affiliated with the military or law enforcement will be canceled. In such cases, a 20% restocking fee will be applied to your refund. By proceeding with your purchase, you acknowledge and agree to these terms.

Ultra High Power Advanced Target Pointer Illuminator
Aiming Laser

L3’s Ultra High Power Advanced Target Pointer Illuminator Aiming
Laser (ATPIAL-UHP) incorporates the capability of the
AN/PEQ-2A with theAN/PEQ-5 into a small, lightweight,
easy-to-use aiming system, hardened for use on all small
arms and crew-served weapons.

FEATURES
• Significantly reduced size and weight over the AN/PEQ-2A
• Co-aligned infrared and visible aiming lasers
in a single device
• 150 mW IR illuminator
• Variable pulsed IR illuminator
• Integral Rail-GrabberTM interface
• Heavy weapon and machine-gun hardened
• Uses single 3 Volt Lithium battery
• Low-battery indicator
• Meets military environmental specifications

CHARACTERISTICS
Dimensions: 4.6 in. L x 2.8 in. W x 1.6 in. H
Weight: 7.75 oz. with battery
Battery Type: (1) 3 Volt Lithium
Battery Life: > 3 hrs. at 25 °C (77 °F)
Visible Aim Laser Specifications at 25 °C (77 °F) Safety Class
Output Power Low: 5.0 mW (max) 3R
Output Power High: 20 (±5) mW 3B
Beam Divergence: 0.5 (±0.3) mrad
Wavelength: 635 (+20/-10) nm
IR Aim Laser Specifications at 25 °C (77 °F) Safety Class
Output Power Low: 650 uW (max) 1
Output Power High: 25 (+10/-2.5) mW 3B
Beam Divergence: 0.5 (±0.3) mrad
Wavelength: 840 (±20) nm
IR Illuminator Specifications at 25 °C (77 °F) Safety Class
Output Power Low: 3.5 mW (max) 3R
Output Power High: 150 (+15/-32) mW 3B
Beam Divergence: 1 to 105 mrad (min)
Wavelength: 840 (±20) nm
